Advanced 3T MRI Scanner System with HighPerformance Accessories for Medical Imaging
Reference: 1600927489076Medical MRI Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Revolutionizing Medical Imaging with Unmatched Precision and Affordability
Experience the future of Magnetic Resonance Imaging with GoldHealth Medical’s cutting-edge MRI systems. Designed for superior performance, our open C-shaped permanent magnet MRI systems deliver exceptional imaging quality while maintaining affordability and operational efficiency.
Why Choose Our MRI System?
- Exceptional Value: Achieve outstanding imaging results without compromising your budget.
- Comprehensive Software Suite: Equipped with advanced applications and intuitive software as standard.
- Patient-Centric Design: The most open C-shaped magnet ensures comfort, even for claustrophobic patients.
- Space Efficiency: Requires less than 50 square meters (538 sq.ft), making it ideal for compact facilities.
- Low Operating Costs: Utilizes a permanent magnet—no helium required, reducing long-term expenses.
- Increased Patient Throughput: Attracts more patients and referrals, boosting your revenue potential.
- Optimized ROI: Lower operational costs paired with high performance ensure maximum profitability.
- Dedicated Support: A professional service team available 24/7 to ensure uninterrupted operation.
Key Specifications
1.0 Magnet
- Field Strength: 0.35 Tesla (3500 Gauss)
- Magnet Type: Full open C-shaped, 2-column design
- Material: Permanent Nd-Fe-B magnet
- Homogeneity: ≤ 2.0ppm (Vrms) at 400mm DSV; ≤ ±1ppm (FWHH) at 200mm DSV
- Shimming: Passive & active shimming
- Patient Gap: 400mm (cover to cover)
- Weight: 17,500 kg
- Dimensions: 1970mm x 1320mm x 1820mm
2.0 Gradient System
- Gradient Strength: Max. 25mT/m (Gx/Gy/Gz)
- Slew Rate: 64mT/M/ms (Gx/Gy/Gz)
3.0 RF System
- Spectrometer: Digital (4 channels)
- Transmitting Coil: Flat planar coil
- Receiving Coils: Phase array coils (Neck, Head, Large Body, Small Body, Knee)
- Optional Coils: Wrist, Shoulder, Spine, Breast, Ankle, and more
- Transmitter Amplifier Power: 6KW
4.0 Computer System
- Operating System: Windows 2000/NT/XP
- CPU: 2.8GHz (Dual Core Processor)
- Hard Disk: ≥250GB
- RAM: 2048MB (2GB)
- Display: ≥22” TFT
- Interfaces: DICOM3.0 compatible with network and laser printer
- Software: BASDA BTI-035 Software
5.0 Auto Pre-scan
- Automated pre-scan functionality for streamlined workflows.
6.0 Pulse Sequences
- Includes IR, Spin Echo (SE 2D/3D), Multi-slice Multi-echo (MSME), Gradient Echo (GRE 2D/3D), Fast Spin Echo (FSE), Single Shot Fast Spin Echo (SSFSE), Inversion Recovery (IR), Fluid Attenuated Inversion Recovery (FLAIR), MRM, MRU, MRCP, TOF 2D/3D MRA, Diffusion Weighted Imaging (DWI), and Echo Planar Imaging (EPI).
7.0 Image Capabilities
- Acquisition Matrix: 64/128/256/512
- Resolution:
- 1mm (Head, 24cm FOV, 256x256)
- 1.5mm (Body, 30cm FOV, 256x256)
- 0.5mm (Head, 24cm FOV, 512x512)
- 0.75mm (Body, 30cm FOV, 512x512)
- Maximum Display Matrix: 1024x1024
- Field of View (FOV): 20mm to 400mm
- Slice Orientation: Sagittal, coronal, transversal, and any oblique angle
- Image Types: T1, T2, T2*, Proton Density, Water/Fat Suppressed, M
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents the 0.35T MRI Machine, a cutting-edge, full-digital magnetic resonance imaging solution designed to deliver exceptional diagnostic accuracy and operational ease. Engineered for versatility, this Class II medical instrument is ideal for hospitals, clinics, research institutions, and rehabilitation centers, offering advanced imaging capabilities with a focus on precision, safety, and user-friendly design.
Key Features and Specifications
- Field Strength: 0.35 Tesla, ensuring high-resolution imaging for accurate diagnostics.
- Spectrometer: Fully digital system for enhanced signal processing and image clarity.
- Acquisition Matrix: Multiple options available (64/128/256/512) to suit diverse clinical needs.
- Maximum Display Matrix: 1024x1024, providing unparalleled detail for precise analysis.
- Ease of Operation: Intuitive interface designed for seamless integration into any medical workflow.
- Material: Durable metal and high-quality plastic construction for long-lasting performance.
- Color: Sleek white finish for a modern, professional appearance.
Safety and Compliance
- Safety Standard: Compliant with GB15979-2002, ensuring the highest levels of safety and reliability.
- Certifications: CE and ISO approved, guaranteeing adherence to international quality standards.
Applications
- Designed for full-digital MRI applications, this machine is suitable for a wide range of medical imaging needs, including soft tissue analysis, neurological studies, and musculoskeletal evaluations.
Warranty and Support
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sales Service: Access to online technical support, ensuring uninterrupted performance and quick resolution of any issues.
Additional Details
- Power Source: Electricity-driven for consistent and reliable operation.
- Shelf Life: 1 year from the date of manufacture.
- Place of Origin: Guangdong, China, reflecting GoldHealth Medical’s commitment to quality craftsmanship.
Why Choose GoldHealth Medical?
GoldHealth Medical’s 0.35T MRI Machine combines advanced technology, robust design, and user-centric features to redefine medical imaging. With its powerful field strength, full-digital spectrometer, and compliance with global safety standards, this MRI machine is a trusted choice for healthcare professionals seeking excellence in diagnostic imaging.
Supply Capability
- Monthly Supply: Up to 1000 sets available to meet high-volume demands.
Experience the future of medical imaging with GoldHealth Medical’s 0.35T MRI Machine – where precision meets innovation.
