64Slice Veterinary CT Scanner for SmalltoMedium Animals with
Reference: 1601216619637Medical MRI Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Revolutionizing Diagnostic Imaging
GoldHealth Medical presents a cutting-edge 64-slice CT scanner designed for both hospital and veterinary applications. This high-resolution CT scanner is engineered to deliver unparalleled diagnostic precision and versatility, making it an indispensable tool for modern healthcare facilities.
Product Highlights
- Flexible Hardware Configurations: Choose between two distinct hardware setups to align with your budgetary requirements without compromising performance.
- Optimized Workflow Efficiency: A robust hardware platform ensures maximum patient throughput, significantly enhancing operational efficiency.
- Intuitive User Interface: Equipped with user-guided controls and auto-positioning presets, this system simplifies procedures ranging from basic head, chest, and abdomen scans to intricate cardiac imaging.
- Superior Image Quality: Achieve exceptional clarity with a high-resolution output of 22lp/cm@0%MTF and 1024x1024 resolution, providing clinicians with greater diagnostic confidence.
- Enhanced Clinical Applications: The 76cm gantry design facilitates tumor biopsy and simulation, expanding the scanner's clinical utility.
Product Specifications
Power Requirements
- Input Voltage: Single phase AC220V
- Supply Frequency: 50Hz
- Power Capacity: Not less than 3.5 kVA
Mechanical Specifications
- Bed Size: Length: 1850mm, Width: 550mm, Height: 730mm (±5% deviation)
- Scanning Frame Size: Length: 1670mm, Width: 810mm, Height: 1600mm (±5% deviation)
- Bed Surface Translation Range: 0–800mm (±5% deviation)
- Bed Lifting Range: 0–150mm (±5% deviation)
- Bearing Capacity: 50kg
Electrical Power
- Maximum Pulse Fluoroscopic Output: 1.875kW (15mA, 125kV, 10s)
- Maximum Continuous Fluoroscopic Output: 1.5kW (12mA, 125kV, 20s)
- Standard Pulse Fluoroscopy Output: 1.6kW (16mA, 100kV, 10s)
- Maximum Continuous Fluoroscopic Output: 1.4kW (14mA, 100kV, 20s)
Loading Factors and Control
- Tube Voltage: 50kV–125kV (adjustable in 1kV steps, ≤±10% deviation)
- Tube Current: 1mA–16mA (adjustable in 1mA steps, accuracy ±1mA)
- Loading Time: 24s (based on external trigger loading time)
Imaging Performance
- Imaging Size: 307.2mm × 245.7mm
- Spatial Resolution: ≥1.7lp/mm
- Imaging Time: ≤40s
Environmental Requirements
- Operating Conditions: Ambient Temperature: 10°C–40°C, Relative Humidity: 30%–75%, Atmospheric Pressure: 70kPa–106kPa
- Transportation and Storage: Ambient Temperature: -20°C–55°C, Relative Humidity: 30%–93%, Atmospheric Pressure: 70kPa–106kPa
Advanced Clinical Applications
- Coronary CTA Case Study: Demonstrates exceptional performance with a heart rate of 70bpm, including premature beats. Parameters: 120kVp, 620mAs, 0.39s rotation speed, scan range 125mm, scan time 11s, slice thickness 0.625mm.
- VR Skeletal Reconstruction: Provides a 3D, intuitive visualization of bone structures, invaluable for orthopedic and plastic surgery planning, especially in complex anatomical cases.
- Curved Planar Reformation (CPR): A post-processing tool that creates 2D panoramic images from 3D volumetric data, ideal for dental evaluations.
GoldHealth Medical is committed to delivering innovative solutions that enhance diagnostic accuracy and improve patient outcomes. Our advanced CT scanner is a testament to our dedication to excellence in medical imaging technology.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
Introducing the GoldHealth Medical 64-Slice CT Scanner, a cutting-edge diagnostic solution designed to deliver unparalleled precision and efficiency. Engineered for modern healthcare environments, this advanced imaging system combines innovative technology with robust performance, making it an ideal choice for hospitals, clinics, research institutions, and more.
Key Features and Specifications
- Imaging Excellence: Achieve exceptional clarity with a slice thickness of just 0.625mm, enabling highly detailed and accurate diagnostic results.
- Powerful Performance: Equipped with an 80kW generator and an 8.0MHU tube, this scanner ensures consistent, high-quality imaging even during extended use.
- Speed and Precision: A rotation speed of 0.39 seconds and a scan time of 11 seconds allow for rapid yet precise imaging, minimizing patient discomfort and optimizing workflow.
- Wide Scan Range: Cover a scan range of 125mm, providing comprehensive imaging capabilities for diverse clinical needs.
- Durable Design: Constructed with premium metal materials, this scanner is built to withstand the demands of busy medical environments.
Technical Details
- Instrument Classification: Class I
- Power Source: Electric
- Shelf Life: 3 years
- Quality Certification: CE
After-Sale Support
GoldHealth Medical is committed to your success. Benefit from 1-year warranty coverage and online technical support, ensuring uninterrupted performance and peace of mind.
Packaging and Delivery
- Package Dimensions: 800 x 700 x 900 cm
- Gross Weight: 600 kg
- Minimum Order Quantity (MOQ): 1 unit
Why Choose GoldHealth Medical?
Our 64-slice CT scanner is more than just a diagnostic tool—it’s a testament to innovation, reliability, and precision. Designed to meet the evolving needs of modern healthcare, this scanner empowers medical professionals to deliver superior patient care with confidence.
Place of Origin: Anhui, China
Experience the future of medical imaging with GoldHealth Medical.
