5KW Mobile Digital XRay MachinePortable Radiology Equipment for Medical Use
Reference: 1600717869332Medical X-ray Equipments & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Portable High Frequency X-ray Machine
Product Overview
GoldHealth Medical presents a revolutionary portable high-frequency X-ray machine designed for medical diagnosis. Engineered for versatility, this device is ideal for examining human limbs and diagnosing conditions in challenging environments such as remote locations, battlefields, sports fields, pet clinics, and emergency rescue scenarios.
Key Features
- Compact and Efficient Design: Combines portability with precision.
- Advanced Digital Display: Equipped with a 6-stage digital LED interface for clear and accurate readings.
- Comprehensive Preset Options: Offers 48 anatomical memory patterns for tailored imaging.
- Precision Control: Utilizes dual digital loops and simulation techniques for exact adjustments of tube voltage and current.
- Self-Diagnostic System: Features automatic failure detection and self-protection mechanisms to ensure reliability.
Technical Specifications
- Input Power: Voltage: AC220VΒ±22V, Frequency: 50/60HzΒ±1Hz
- Power Capacity: β₯5kVA; Inner resistance β€0.5Ξ©
- Maximum Output Power: P = 110kV Γ 50mA = 5kW
- Nominal Power: 50kV, 100mA, 0.1s, 5kW
- kV Adjustment Range: 40kV to 110kV in 1 kV increments
- mA Adjustment Range: 20mA to 100mA
- mAs Adjustment Range: 0.2mAs to 200mAs
- Exposure Time: 0.01S to 4S
- X-ray Tube:
- Focus: 0.6/1.8mm
- Anode Heating Capacity: 40KJ
- Dimensions: 290Γ260Γ230mm
- Weight: 18.8kg
Optional Stands
- Stand A
- Stand B
Related Products
- Floor Mounted Automated DR X-ray System: High-performance radiography for advanced medical facilities.
- Mobile High Frequency Radiography Machine: Combines mobility with cutting-edge imaging technology.
- Digital Flat Panel Detectors: Available in various sizes for both human and veterinary use.
- Dry Thermal Imager Medical X-Ray Film Printer: Ensures high-quality image printing for diverse diagnostic needs.
Why Choose GoldHealth Medical?
GoldHealth Medical has over two decades of expertise in delivering top-tier medical equipment. Our commitment to quality and competitive pricing has earned us a strong reputation globally, particularly in Africa, the Middle East, Europe, Asia, and South America.
Frequently Asked Questions
- Price Level: Our prices are competitive, reflecting our dedication to providing high-quality products.
- Product Quality: We prioritize original designs and rigorous quality control, setting us apart from cheaper alternatives.
- Delivery Time: Typically 15 days post-order confirmation, with expedited options for small or sample orders.
- Quality Assurance: We offer a one-year warranty, including free spare parts and replacements as needed.
- Payment Terms: Flexible options including T/T, Credit Card, L/C, Western Union, PayPal, and MoneyGram.
GoldHealth Medical's portable X-ray machine is not just a tool; it's a reliable partner in delivering precise diagnostics wherever you need it.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical presents a cutting-edge Class II medical instrument designed to deliver exceptional performance and reliability in diagnostic imaging. Engineered with precision, this device combines advanced technology with robust materials to meet the rigorous demands of modern healthcare environments. Whether for hospitals, clinics, or research facilities, this product ensures unparalleled accuracy and safety.
Key Features
- Powerful Performance: Maximum output power of 5kW with a nominal power rating of 50kV and 100mA ensures consistent and reliable operation.
- Precision Control: mA adjusting range of 20mA to 100mA and mAs adjusting range of 0.2mAs to 200mAs allows for fine-tuned imaging parameters.
- Flexible Exposure Settings: Exposure time adjustable from 0.01 seconds to 4 seconds for optimal image capture across diverse applications.
- Durable Construction: Crafted from high-quality materials including metal, plastic, and steel for long-lasting durability and stability.
Technical Specifications
- Power Source: Electricity
- Nominal Power: 50kV, 100mA, 0.1s, 5kW
- mA Adjusting Range: 20mA - 100mA
- mAs Adjusting Range: 0.2mAs - 200mAs (shifted adjustment)
- Exposure Time: 0.01S - 4S
- Maximum Output Power: 5kW
Quality Assurance
- Backed by a 1-Year Warranty and comprehensive quality certification, including CE approval.
- After-Sale Support: Access to online technical support ensures seamless operation and troubleshooting.
Applications
This versatile instrument is ideal for hospitals, clinics, laboratories, rehabilitation centers, and home healthcare settings. Its advanced capabilities and user-friendly design make it an indispensable tool for medical professionals seeking precision and reliability.
Place of Origin: Jiangsu, China
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare providers worldwide. Experience the perfect blend of technology, durability, and precision with this state-of-the-art medical instrument.
