5Kw High Frequency DR Flat Panel Detector XRay System Mobile Digital Radi
Reference: 1600683584053Radiology Equipment & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Portable Digital X-Ray System
Experience the future of diagnostic imaging with GoldHealth Medical’s Portable Digital X-Ray Machine. Designed for precision, portability, and ease of use, this state-of-the-art system is engineered to meet the needs of modern healthcare environments. Whether in hospitals, clinics, or remote settings, this system delivers exceptional image quality and operational efficiency.
Key Features
- Simplified & Lightweight Design: Compact and easy to maneuver, making it ideal for both stationary and mobile applications.
- LED Digital Display: Clear, intuitive interface for seamless operation.
- Anatomical Memory Programs: Pre-set configurations for different anatomical regions, ensuring optimal imaging parameters.
- Dual-Loop Precision Control: Combines analog and digital control for unparalleled accuracy in tube voltage and current regulation.
- Advanced Self-Protection: Equipped with auto-diagnosis capabilities to detect and respond to malfunctions, ensuring consistent performance.
- Exceptional Portability: Lightweight design allows for effortless transportation and setup, even in confined spaces.
Technical Specifications
- Power Output: 5kW
- Power Supply: Single-phase 220V, 50/60Hz (wire diameter >4mm², internal resistance <0.5Ω)
- Working Frequency: 30kHz
- mA Range: 32-100mA
- mAs Range: 0.32-315mAs
- kV Range: 40-110kV
- Exposure Time: 0.01-6.3 seconds
- Tube Focus: 1.8 x 1.8mm
- Anode Heat Capacity: 42kHU
Flat Panel Detector
- Image Size: 17 x 17 inches (optional 14 x 17 inches)
- Pixel Matrix: 140μm
- A/D Conversion: 16-bit
- Spatial Resolution: 3.6 Lp/mm
Software & Computing
- Professional Imaging Software: Advanced tools for image enhancement, analysis, and reporting.
- Integrated Computer: Powered by R5-5500U processor, 8GB RAM, and 512GB storage for rapid processing and data management.
Why Choose GoldHealth Medical?
GoldHealth Medical is a trusted innovator in diagnostic imaging solutions, offering cutting-edge technology and unmatched reliability. Our portable X-ray systems are designed to outperform traditional models, combining superior image quality with lightweight portability. Trusted by over 2,000 healthcare institutions worldwide, our products are built with components shared by national aerospace projects, ensuring the highest standards of quality and durability.
Applications
- Hospitals and Clinics
- Research Laboratories
- Mobile Diagnostic Units
- Rehabilitation Centers
- Veterinary Practices
- Home Healthcare
GoldHealth Medical’s Portable Digital X-Ray Machine is more than just a diagnostic tool—it’s a gateway to better healthcare. Elevate your facility’s capabilities with a system that combines precision, portability, and performance.
For inquiries or further details, contact us today.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Portable Digital X-Ray Machine by GoldHealth Medical
Product Overview:
Elevating diagnostic precision with cutting-edge technology, the Portable Digital X-Ray Machine from GoldHealth Medical is designed for versatility and reliability. Engineered to meet the demands of modern healthcare environments, this device delivers exceptional imaging quality while maintaining portability and ease of use. Ideal for hospitals, clinics, laboratories, and home care settings, it ensures accurate diagnostics without compromising safety or efficiency.Key Features:
- Powerful Imaging Performance: Equipped with a robust 5kW power output, this machine supports a wide range of diagnostic applications.
- Advanced Technical Specifications:
- Power Supply: Single-phase 220V, 50/60Hz
- Working Frequency: 30kHz
- mA Range: 32-100mA
- mAs Range: 0.32-315mAs
- KV Range: 40-110kV
- Exposure Time: 0.01-6.3 seconds
- Tube Focus: 1.8*1.8mm
- Anode Heat Capacity: 42kHU
Durable Construction: Built with high-quality materials including metal, plastic, and steel, ensuring long-lasting performance under demanding conditions.
Safety and Compliance:
- Instrument Classification: Class II
- Safety Standard: GB15979-2002
Quality Certifications: ISO, CE
Portability and Convenience:
Compact and lightweight design with a single package size of 120x120x120 cm and a gross weight of 150 kg, making it easy to transport and install.
Warranty and Support:
- Comprehensive 1-Year Warranty
Dedicated Online Technical Support to ensure seamless operation and address any technical queries.
Applications:
Designed for diverse medical environments, including hospitals, research institutions, rehabilitation centers, and home healthcare, this portable X-ray machine is a reliable solution for accurate and efficient diagnostics.
Choose GoldHealth Medical’s Portable Digital X-Ray Machine for unmatched precision, durability, and performance in medical imaging.
