5inch Portable MultiParameter Medical Monitor System
Reference: 1600732641619Examination Therapy Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Product Overview
GoldHealth Medical introduces a state-of-the-art patient monitor designed for clinical use in operating rooms, postoperative recovery areas, ICU/CCU wards, emergency rooms, outdoor first aid, and more. This versatile device is suitable for monitoring adults, pediatrics, and neonates, providing critical insights into vital parameters such as ECG, SpO2, PR, NIBP, TEMP, and optional EtCO2. Monitored data can be displayed, stored, reviewed, and printed, empowering healthcare professionals with actionable information.
Key Advantages
- Comprehensive Monitoring: Tracks ECG, NIBP, SpO2, PR, TEMP, and optional EtCO2.
- Data Management: Enables downloading, reviewing, printing, and secure storage of patient data.
- Remote Diagnosis: Bluetooth-enabled Android app allows doctors to access patient records remotely for timely diagnosis.
- Extensive Storage: Stores up to 3,888 trend data groups, 30 ECG waveforms, and 100 patient data sets.
- Intuitive Display: Features a 5-inch TFT-LCD touchscreen with adjustable backlight for optimal visibility.
- Smart Alarms: Provides both audio and visual alerts for enhanced patient safety.
- Portability: Compact design (20×10×5 cm, 655g) with a rechargeable Li-ion battery offering up to 15 hours of continuous operation.
- Versatility: Suitable for long-term monitoring of adults and children, with optional pediatric and EtCO2 accessories.
Technical Parameters
ECG
- Input: 5-lead ECG cable with standard AAMI connector.
- Lead Selection: I, II, III.
- Gain Selection: ×1, ×2, ×4, ×8.
- Sweep Speed: 12.5, 25, and 50 mm/s.
- Frequency Response:
- No filter: 0.05–100Hz (-3dB).
- Filter: 0.5–40Hz (-3dB).
- Calibration Signal: 1mV square wave.
- Protection: Resists electrosurgical interference and defibrillation.
Heart Rate
- Range: 20–300 bpm.
- Renew Time: Updates with every heartbeat.
- Accuracy: ±1 bpm.
- Alarm Mode: Audible and visual alerts.
SpO2
- Range: 0%–100%.
- Resolution: 1%.
- Accuracy:
- ±2% (90%–99%).
- ±3% (70%–89%).
- Unspecified (0%–69%).
Pulse Rate
- Measuring & Alarm Range: 20–300 bpm.
- Resolution: 1 bpm.
- Accuracy: ±1 bpm.
Temperature
- Input: Body surface thermal-sensitive resistor temperature sensor.
- Measuring Range: 0°C–50°C.
- Accuracy: ±0.1°C.
NIBP
- Method: Oscillometric.
- Modes: Manual, Auto, STAT.
- Measuring Interval in AUTO Mode: 1, 2, 3, 5, 10, 15, 20, 30, 45, 60 minutes.
- Measuring Period in STAT Mode: 5 minutes.
- Measuring Types: SYS, DIA, MAP.
- Resolution: 1 mmHg.
- Over-pressure Protection: Yes.
Package Contents
- Patient Monitor Main Unit (Battery Included).
- 5-lead ECG Cable with TEMP Probe.
- Adult NIBP Cuff.
- NIBP Extension Tube (1.5m).
- Adult SpO2 Sensor (2m).
- AC Power Adapter.
- Wall Bracket.
- Electrodes.
- User Manual.
Dimensions & Weight
- Device Dimensions: 20.9cm x 10.4cm x 4.75cm.
- Net Weight: 0.65Kg.
- Gross Weight (with Accessories): 3Kg.
- Packing Size: 29cm x 27cm x 17cm.
Certifications
GoldHealth Medical has over 24 years of expertise in research, manufacturing, and sales, ensuring precision, safety,
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents an advanced medical monitoring solution designed to elevate patient care with precision and reliability.
- Instrument Classification: Class II medical device, ensuring safety and performance in critical healthcare environments.
- Place of Origin: Proudly crafted in China with globally recognized quality standards.
- Power Source: Electric, offering consistent and dependable operation.
- Shelf Life: 5 years, providing long-term usability and value.
- Quality Certification: CE-certified, guaranteeing compliance with international safety and performance benchmarks.
Standard Parameters: - ECG: Accurate heart activity monitoring for reliable diagnostics. - SpO2: Real-time oxygen saturation tracking to ensure optimal patient health. - NIBP: Non-invasive blood pressure measurement for convenience and precision. - PR: Pulse rate monitoring to support comprehensive patient assessment. - TEMP: Precise temperature readings for effective health management.
Optional Parameter: - EtCO2: Enhanced end-tidal carbon dioxide monitoring for advanced respiratory care.
Product Specifications: - Dimensions: Compact design at 20.9 x 10.4 x 4.75 cm, ensuring portability and ease of use in diverse settings. - Weight: Lightweight at just 655g, making it ideal for both stationary and mobile applications. - Packaging Details: - Single item per package. - Package dimensions: 30 x 27 x 20 cm. - Gross weight per package: 3.000 kg.
Support and Assurance: - Warranty: Comprehensive 1-year warranty for peace of mind. - After-Sale Service: Access to online technical support, ensuring uninterrupted performance and expert assistance whenever needed.
Why Choose GoldHealth Medical? Our device combines cutting-edge technology with user-centric design, delivering unparalleled accuracy, versatility, and durability. Whether for hospitals, clinics, research labs, or home care, this solution is engineered to meet the highest standards of modern healthcare.
