5Axis Zirconia Dental Milling Machine for CADCAM Labs
Reference: 1601251008637Dental Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Zirconia Milling Machine for Dental Laboratories
GoldHealth Medical presents an advanced five-axis CAD/CAM dry-cutting dental milling machine designed for precision and versatility. This compact and user-friendly system is engineered to adapt seamlessly to diverse working environments, making it ideal for dental laboratories of all sizes.
Unparalleled Performance and Precision
Our milling machine utilizes a sophisticated servo motor system across its five axes, ensuring rapid and stable processing of various dental materials within the CAD/CAM workflow. It delivers exceptional accuracy with: - Positioning accuracy of 0.01mm - Repeated accuracy of 0.005mm - A-axis rotation of +25° and B-axis rotation of 360°
Key Features
- Lightweight and Modern Design: Combines elegance with functionality in a compact form.
- Versatile Material Compatibility: Processes zirconia, wax, resin, PMMA, and PEEK with ease.
- Advanced Correction Functionality: Ensures consistent precision.
- High-Performance Spindle: Operates at 60,000 rpm with 500W power and air cooling.
- Intelligent Alerts: Keeps users informed with smart notifications.
- 7-inch High-Resolution Touchscreen: Offers intuitive control and monitoring.
- Automatic Tool Change: Supports up to 5 tools with 4mm diameter.
- Efficient Processing Times:
- Zirconia: 8 minutes
- Wax: 3 minutes
Applications
This state-of-the-art machine is capable of producing a wide array of dental restorations, including: - Crowns - Bridges - Veneers - Inlays - Temporary crowns - Telescopic crowns
Technical Specifications
- Device Dimensions: 580mm x 570mm x 520mm
- Device Weight: 80kg
- Power Input: Single Phase AC 220V, 50/60Hz, 5kW
- Air Pressure Requirement: Above 0.6Mpa
- Clamp Size: 98.5mm diameter disc clamp
GoldHealth Medical's zirconia milling machine represents a powerful, efficient, and intelligent solution for dental restoration needs. Designed to meet the demands of modern dental practices, it combines affordability with cutting-edge technology, setting a new standard in dental milling solutions.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents the D500 Dental Milling Machine – Precision Redefined for Modern Dental Laboratories
Device Overview:
The D500 Dental Milling Machine is engineered to deliver unparalleled precision and reliability, making it the ideal choice for crafting high-quality dental prosthetics. Designed with cutting-edge technology, this machine ensures consistent accuracy and efficiency for every application.Key Features:
- Exceptional Precision: Achieves a positioning accuracy of 0.01mm and a repeated accuracy of 0.005mm, ensuring flawless results every time.
- High-Speed Spindle: Equipped with a 60,000rpm/min spindle speed and 500W spindle power for rapid, smooth milling operations.
- Advanced Rotation Axes: A-axis rotates up to +25° and B-axis offers a full 360° rotation, enabling complex geometries with ease.
Durable Construction: Built with premium metal and steel materials, ensuring long-lasting performance in demanding environments.
Technical Specifications:
- Power Input: Single Phase AC 220V, 50/60Hz, 5kW
- Air-Pressure Input: Above 0.6Mpa
- Clamp System: 98.5mm diameter disc clamp for secure material handling
- Device Dimensions: 580mm x 570mm x 520mm
Device Weight: 80kg
Certifications and Standards:
- Complies with Class I Instrument Classification and GB15979-2002 Safety Standard
Backed by CE Quality Certification for global reliability
Packaging Details:
- Single package size: 62cm x 60cm x 60cm
Single gross weight: 90kg
Warranty and Support:
- 2-Year Warranty: Demonstrates our confidence in the machine’s durability and performance.
Online Technical Support: Access expert assistance anytime to ensure uninterrupted productivity.
Shelf Life: 3 years
The GoldHealth Medical D500 Dental Milling Machine is more than just equipment – it’s a commitment to excellence in dental craftsmanship. Elevate your laboratory’s capabilities with a machine that combines precision, power, and reliability.
