2024 New Digital Handheld XRay Machine DR Flat Panel Detector
Reference: 10000018052186Medical X-ray Equipments & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Revolutionizing Medical Imaging with GoldHealth Medical
Introducing the Ultimate Portable X-ray Solution
GoldHealth Medical presents a groundbreaking handheld digital X-ray machine, designed to redefine radiology workflows across diverse medical environments. This all-in-one device combines portability, precision, and performance, making it an indispensable tool for modern healthcare providers.
Why This Device Stands Out
- Compact and Versatile: Engineered for mobility, this lightweight system is ideal for hospitals, clinics, field operations, remote medical services, and forensic applications.
- Battery-Powered Flexibility: Operates seamlessly on a high-performance battery, enabling exposures in any direction without reliance on external power sources.
- Wireless Freedom: Eliminates the need for dedicated physical spaces, offering unparalleled convenience for imaging in confined or unconventional settings.
- Instant Image Review: Capture and review images directly on the device before wirelessly transmitting them to a PC via the integrated workstation.
Applications Across Healthcare
- Comprehensive diagnostic centers
- Hospital radiology departments
- Radiological imaging facilities
- Emergency rooms
- Orthopedic departments
- Lung diagnosis centers
- Veterinary hospitals
Key Features
- Minimal Space Requirements: Compact design ensures easy integration into any workspace.
- Low Radiation Dose: Prioritizes patient and operator safety with optimized exposure parameters.
- Industry-Leading Battery Life: Maximizes efficiency with extended operational capacity.
- Plug-and-Play Operation: Begin imaging immediately with an intuitive software interface and built-in workstation.
- Completely Wireless: No installation or additional equipment needed, boosting productivity.
- Superior Performance: Delivers exceptional image quality with advanced detector technology.
Technical Specifications
- Operating Parameters:
- Input: Mono-phase, AC power 220V±10%, 50Hz±1Hz
- Output: 25.2 VDC, 1.5A
- Battery: 22.2V (polymer lithium-ion), 2200mAh
- kV Range: 50–70 kV (adjustable in 1 kV increments)
- mA Range: 2–5 mA (adjustable in 1 mA increments)
X-ray Release Time: 0.03–0.20 seconds (10ms steps), 0.20–2.00 seconds (50ms steps)
Display:
7-inch screen with 1024x600 resolution
X-ray Tube:
- Model: C.E.I OX/70-3
- Inherent Filter: 0.5mm AL
Focus Point: 0.3 x 0.3mm
Dimensions and Weight:
Device: 285mm x 265mm x 168mm (LxWxH), 3.2kg±5%
Detector Options:
BW-1717W:
- Dimensions: 460×460×15mm
- Effective Imaging Area: 433.5×433.5mm
- Pixel Matrix: 2816×2816
- Pixel Size: 154µm
- Spatial Resolution: 3.1 Lp/mm
- Quantum Detection Efficiency:
- 0.5 lp/mm: 60%
- 1.0 lp/mm: 55%
- 1.5 lp/mm: 45%
- 2.0 lp/mm: 40%
- 2.5 lp/mm: 30%
- Battery: 14.8V, 3260mAh
- Power: Max. 36 VA
- Weight: ~4.1kg
BW-1717X:
- Dimensions: 460×460×15mm
- Effective Imaging Area: 426.7×426.7mm
- Pixel Matrix: 4267×4267
- Pixel Size: 100µm
- Spatial Resolution: 4.0 Lp/mm
- Quantum Detection Efficiency:
- 0.5 lp/mm: 65.8%
- 1.0 lp/mm: 55.9%
- 1.5 lp/mm: 47.5%
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: Handheld Digital X-Ray Machine by GoldHealth Medical
Key Features and Benefits:
- Precision Redefined: Capture high-resolution X-ray images with a 7-inch screen (1024x600 resolution) for unparalleled clarity and diagnostic accuracy.
- Portability Meets Power: Weighing just 3.2kg±5%, this compact device is designed for effortless mobility, making it ideal for diverse medical environments.
- Advanced Imaging Technology: Equipped with a polymer lithium-ion battery (22.2V, 2200mAh), ensuring reliable performance even in remote or off-grid settings.
- Safety First: Compliant with Class II instrument classification and GB/T 32610 safety standards, ensuring secure operation for both patients and practitioners.
- Durability and Reliability: Constructed with premium metal and steel materials, built to withstand demanding clinical use.
Technical Specifications:
- Power Source: Mono-phase, AC power 220V±10%, frequency 50Hz±1Hz
- Output: 25.2 VDC, 1.5A
- Battery Life: 22.2V (polymer lithium-ion), 2200mAh
- Screen: 7 inches, resolution 1024x600
- Dimensions: 285mm x 265mm x 168mm (length x width x height)
- Weight: 3.2kg±5%
Packaging and Delivery Details:
- Selling Unit: Single item
- Package Size: 45cm x 40cm x 40cm
- Gross Weight: 20.000 kg
Warranty and Support:
- Comprehensive Warranty: 1-year coverage for peace of mind.
- Dedicated After-Sales Service: Access to online technical support, ensuring seamless operation and troubleshooting assistance.
Certifications:
- CE and GB/T 32610 compliance, guaranteeing adherence to international quality and safety standards.
Applications:
Perfect for hospitals, clinics, research labs, rehabilitation centers, and home healthcare, this handheld X-ray machine is a versatile tool for modern medical diagnostics.
GoldHealth Medical is committed to delivering innovative, reliable, and cutting-edge medical solutions that empower healthcare professionals worldwide.
