2023 Advanced CT Scanner 16128 S
Reference: 1600900045300Radiology Equipment & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical CT Scanner
Gantry
- Aperture: 76cm for enhanced patient comfort and accessibility.
- One-button positioning: Simplifies operation with preset protocols.
- Scan Speed: Multiple options ranging from 0.48s to 2.0s per 360° rotation.
- Scan Field of View (FOV): 50cm, ensuring comprehensive imaging.
- Tilt Range: Mechanical tilt of ±30° with precise 0.5° increments.
- Display Panel: 13.3-inch LCD showing real-time scan parameters.
- Auto Voice Support: Integrated for seamless communication.
- ECG Cable Connection: Conveniently located on the front control panel.
Patient Table
- Max Horizontal Travel Range: 1950mm, providing extensive coverage.
- Horizontal Scannable Range: 50mm to 1860mm.
- Horizontal Travel Speed: Adjustable from 1mm/s to 200mm/s.
- Vertical Table Travel Range: 425mm to 990mm.
- Max Table Load: Supports up to 250kg.
- One-key Patient Table Release: Ensures quick and easy adjustments.
- Patient Table Cradle Switches: Facilitates effortless control.
X-ray Tube
- Anode Heat Capacity: 5.3MHU for sustained performance.
- Cooling Rate: Efficient at 815kHU/min.
- Focal Spot Size: Large (1.0mm x 1.0mm) and Small (0.5mm x 1.0mm).
Generator
- Power Rating: 50.4kW for robust imaging capabilities.
- kV Settings: Versatile options at 70, 80, 100, 120, and 140kV.
- mA Range: 10 to 420mA with precise 1mA increments.
Detector
- Material: Solid-state GOS for superior image quality.
- Number of Detector Rows: 64 rows.
- Max Slices per Rotation: 128 slices.
- Detector Channels per Row: 864 channels.
- Total Detector Elements: 55,296 elements.
- Min Slice Thickness: 0.625mm for detailed imaging.
- Detector Width: 40mm.
- Max Data Sampling Rate: 4800 views per 360°.
Scanning Performance
- Scout Scan: Supports A.P., lateral, and dual modes.
- Scannable Range: 50mm to 1860mm.
- Acquisition Modes: 128 x 0.625mm, 64 x 0.625mm, 32 x 0.625mm.
- Collimation Width Selection: Options include 40mm, 20mm, 15mm, and 10mm.
- Pitch Factor: Adjustable from 0.2 to 1.75.
- Max Continuous Scan Time: Up to 100 seconds.
Image Reconstruction
- Reconstruction FOV: 50mm to 500mm, extendable to 650mm.
- Reconstruction Matrices: 512x512, 768x768, 1024x1024.
- Reconstruction Speed: ≥40 images per second, reaching up to 42-28 ips.
- Display Matrix: 1024 x 1024 for high-resolution visuals.
Image Optimization Algorithm
- Artifact Reduction: Comprehensive reduction of metal, beam hardening, partial volume, streaking, helical scan, and motion artifacts.
- Advanced Motion Artifact Correction: Utilizes third-generation deep learning algorithms for precise artifact modeling and compensation.
Image Quality
- Spatial Resolution: ≥21 lp/cm @ 0% MTF in X-Y plane, ≥15 lp/cm @ 0% MTF in Z plane.
- Low-Contrast Resolution: 2mm @ 0.3% @ 18mGy.
- Image Noise: ≤0.35% at central dose ≤40 mGy.
- CT HU Scale: Standard (-1024HU to +3072HU), Extended (-32768HU to +32767HU).
Cardiac Scan
- ECG Scan Support: Prospective and
